Example of a Körting vacuum system in practice
This four-stage steam jet vacuum system with mixing condensers demonstrates Körting’s capability in designing efficient solutions for demanding industrial processes. Two series-connected ejector stages achieve suction pressures down to 1 mbar, depending on cooling water temperature, while keeping motive steam consumption low. Two additional stages compress non-condensable gases to atmospheric pressure. The integrated mixing condenser improves energy efficiency by condensing motive steam from the upstream ejector.
